Product Highlights

EL8 – High-Dynimac electronic control unit for open and closed loop systems

• Digital electronic control unit in DIN rail execution
• Designed to control single or double solenoid hydraulic valves
• Ability to control standard, bipolar or high-dynamic proportional valves (PRL2) of all sizes
• Suitable also for open or closed loop systems
• Wide range of supply voltage from 10,8 up to 28,8 V DC
• PWM frequency up to 22 kHz • Quick response time (0,1 ms)
• Parameterized by desktop application via USB-C
• Controlled by analogue input command signal (multiple types available)
• Resistant to interferences, electrostatic discharge and quick transients
• Flexible and reliable function of system achieved by using a fast 32-bit ultra-low-power processor
• The 12-bit A/D converter assures high resolution and accuracy conversion of input command signal
